IHI TURBOCHARGER R163 SPARE PARTS
IHI R163 Turbocharger Spare Parts Supply & Overhaul
● Price available upon request
As YAF Diesel, we supply a comprehensive range of spare parts for the IHI R163 turbocharger used on large marine and power-plant engines. From rotor shafts and turbine blades to nozzle rings and bearings, we support maintenance and overhauls with Genuine, OEM, and certified reconditioned solutions coordinated from our Istanbul Tuzla hub.
IHI R163 Spare Parts Available From Stock
- Rotor Shaft / Rotor Complete
- Compressor Wheel (Impeller, Inducer)
- Turbine Blades
- Nozzle Ring & Cover Ring
- Plain & Axial Bearings
- Sealing Bush Set
- Gear / Lube Oil Pumps & components
- Gas Inlet Casing
- Gas Outlet Casing
- Gasket & Overhaul Kits
- Filters & Silencers
Technical Specifications (IHI R163)
| Make | IHI |
|---|---|
| Type | R163 |
| Max. Speed | 1150 /N max |
| Max. Temp. | 650°C |
Detailed Parts List (R163)
| P/N | Description |
|---|---|
| 1001 | Turbine Shaft |
| 1002 | Thrust Collar |
| 1004 | Distance Piece |
| 1006 | Sealing Bush |
| 1008 | Shaft End Hexagon Nut |
| 1009 | Seal Ring (Turbine Side) |
| 1010 | Seal Ring (Compressor Side) |
| 2001 | Compressor Wheel |
| 3001 | Compressor Housing |
| 3002 | Compressor Side Clamp |
| 3003 | Hexagon Head Bolt M8×16 |
| 4001 | Turbine Housing |
| 4002 | Turbine Side Clamp |
| 4004 | Hexagon Head Bolt M10×20 |
| 5001 | Bearing Housing |
| 5002 | Snap Ring |
| 5003 | Hexagon Head Bolt M6×30 |
| 5004 | Spring Lock Washer 6 |
| 5005 | Heat Shield |
| 5006 | O-Ring G90 |
| 5007 | Parallel Pin |
| 5008 | O-Ring |
| 5013 | Metal Seal Gasket |
| 5014 | Plug |
| 6001 | Seal Plate (Turbine Side) |
| 6002 | Floating Journal Bearing |
| 7001 | Floating Journal Bearing |
| 7002 | Thrust Bearing |
| 8001 | Silencer |
| 8002 | Air Filter |
| 8003 | Hexagon Head Bolt M8×34 |
| 8004 | Spring Lock Washer 8 |
| — | Turbine Housing 70-1 |
| — | Turbine Shaft 10-1 |
| — | Compressor Wheel 20-1 |
| — | Floating Journal Bearing 60-1 |
| — | Thrust Housing 60-2 |
| — | Bearing Housing 50-1 |
| — | Heat Shield 50-7 |
| — | O-Ring 50-6 |
| — | Snap Ring 50-3 |
| — | Sealing Bush 10-5 |
| — | Thrust Collar (Bearing Side) 10-2 |
| — | Thrust Collar (Compressor Side) 10-4 |
| — | Sealing Ring 10-7 |
| — | Distance Piece 10-3 |
Auxiliary Engine Major Spares
- Cylinder Head / Cylinder Cover
- Cylinder Liner / Block
- Piston / Piston Pin / Rings
- Connecting Rod
- Crankshaft / Flywheel
- Bedplate / Camshaft
- Fuel Pump / Governor
- Lub Oil / Fresh Water Pump
- Oil & After Coolers
Frequently Asked Questions (FAQ)
Do you supply Genuine, OEM and Reconditioned parts for IHI R163?
Yes. We offer Genuine original parts, OEM items, and certified reconditioned main components (balanced and tested) to match budget and lead-time needs.
Can you support class or third-party inspections?
We provide in-house technical facilities and arrange class approval or third-party surveys (DNV, LR, BV, ABS) upon request.
Do you deliver worldwide?
Yes. We ship globally with fast handling from our Tuzla - Istanbul warehouse.
Request technical quote for IHI R163 parts
